Industrial Low Pressure Check Valve / API 598 Stainless Steel Check Valve

Industrial Low Pressure Check Valve / API 598 Stainless Steel Check Valve
Industrial Low Pressure Check Valve / API 598 Stainless Steel Check Valve

Large Image :  Industrial Low Pressure Check Valve / API 598 Stainless Steel Check Valve

Product Details:
Place of Origin: Shanghai , China
Brand Name: OEM
Certification: ISO 9001/ API 6D
Model Number: H44-150
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Usually packing by plywood case suit for sea delivery
Delivery Time: 1usually within 35 days after received your payment
Payment Terms: T/T advance or L/C at sight
Supply Ability: 90,000pcs per month
Detailed Product Description
Product Name: Low Pressure Check Valve Size: DN15 ~DN600
Pressure: 150/300/600/800/900/1500/2500lbs Standard: API 6D/ ANSI 16.5 B/ JIS 20K/JIS 10K
Temperature: -29~425 C Body: A216 WCB
Seat: Stainless Steel/ 2Cr13 Disc: A216 WCB
High Light:

non return valve

,

ductile iron swing check valve

Industrial Low Pressure Check Valve / API 598 Stainless Steel Check Valve



Check Valve 150Lbs RF STL F6 Trim BB Swing Dia 4" Mat ASTM A 216 Grade WCB or WCC



CHECK VALVE, CARBON STEEL, SWING,

RAISED FACE FLANGE, 400 DEG F (DESIGN),

FLANGED RAISED FACE TO ANSI B16.5

CONFORMING TO LATEST EDITION OF API 6D

AND SUITABLE FOR SOUR SERVICE NACE MR0175,

MATERIAL SPECIFICATION SHALL BE AS PER CLAUSE 6.6 /

MAXIMUM HARDNESS HB197

BODY MATERIAL: CARBON STEEL

TYPE: SWING

CONFIGURATION: FULL BORE

CONNECTION: RAISED FACE FLANGE

TEMPERATURE RATING: 400 DEG F (DESIGN)

SPECIFICATION: AS API 6D



Specifications:



Swing Check Valve 8" 150# Flanged RF - B16.5 / B16.47 FB - Bolted Cover
Body Material: A216 WCB
Ball/Disc/Plug: F6 (13% Cr.) / Seat Ring : CS+Stellite 6
Body Gasket : 304+Flex Graphite, Bolting : A193-B7M / A194-2HM, NACE MR-01-75



Standards



Design and manufacture as BS1868, ANSI B16.34
Face to face dimensions as ANSI B16.10
End flange dimension as ANSI B16.5
Pressure-temperature ratings as ANSI B16.34
Pressure test as API 598
Applicable Medium: water ,gas,oil,and other causticity medium.





Test Pressure



 Test Item

Shell Test

Seal Test

 Back Seal Test

 Air Seal Test

 Medium

 Water

 Air

Unit

MPa

lbf/in2

MPa

lbf/in2

MPa

lbf/in2

MPa

lbf/in2

Pressure (Class)

150

3.1

450

2.2

315

2.2

315

0.5-0.7

60-100

300

7.8

1125

5.6

815

5.6

815

400

10.3

1500

7.6

1100

7.6

1100

600

15.3

2225

11.2

1630

11.2

1630

900

23.1

3350

16.8

2440

16.8

2440

1500

38.4

5575

28.1

4080

28.1

4080



Brief introduction:

The check valve is designed and manufactured according well to API 6D and ANSI B 16.34.  It can

 work in

high temperature and pressure circumstance. It also have the features of good appearance, nice

function and

 superior. Widely used for petroleum, chemistry, water treatment industries.



Features:



- Resist friction

Valve disc is given enough intensity and rigidity. Disc sealing surface may be built up welded with

 satellite alloy inlaid or other material responding to the users’ request.



- Agility of switch

Solid ping is precisely installed and provided with high intensity to ensure operational performance

and service life of valve.



- Sealing credibility

The check valve adopt swing configuration. All the sealing part inside the valve, so all exterior leak

may except the middle flange, and also the middle flange gasket may be different



according to pressure class.

- Distortion compensating

The disc and the hinge are connected between slippery spherical surface, and this makes the disc

can circumgyrate in a little angle and regulates the sealing capability.



Mail part & material



Item Name of parts

material

1

Body

WCB,CF8

2

Seat

304,A105+ satellite

3

Disc

304,A105+ satellite

4

Gasket

Graphite+304

5

Bonnet

WCB,CF8

6

Yoke

WCB,CF8

7

Hinge

WCB,CF8,2Cr13

8

Hinge pin

2Cr13,304





Main Connection Dimensions





Type

 Size(mm)

 Dimension(mm)

inch

DN

L

D

D1

D2

b

z-Φd

H

H44H/W/Y-150Lb

1″

25

127

108

79.5

51

12

4-Φ15

90

11/2″

40

165

127

98.5

73

15

4-Φ15

115

2″

50

203

152

120.7

92

16

4-Φ19

150

21/2″

65

216

177.8

139.7

104.7

18

4-Φ19

160

3″

80

241

190.5

152.4

127

19

4-Φ19

180

4″

100

292

229

190.5

157

24

8-Φ19

220

5″

125

330

254

216

185.7

26

8-Φ22

280

6″

150

356

279

241.3

216

26

8-Φ22

340

8″

200

495

343

298.5

270

29

8-Φ22

400

10″

250

622

406

362

324

31

12-Φ25

460

12″

300

698

483

432

381

32

12-Φ25

530

14″

350

787

533

476.3

413

35

12-Φ29

580

16″

400

864

597

540

470

37

16-Φ29

600

18″

450

978

635

578

533.4

40

16-Φ32

650

20″

500

978

698 5

635

584

43

20-Φ32

700

24″

600

1295

813

749.3

692

48

20-Φ35

780

28″

700

1448

927

863.6

800

72

28-Φ35

850

30″

800

1524

984

914.4

857

75

28-Φ35

920





































































 Type

Size(mm)

Dimension(mm)



inch

DN

L

D

D1

D2

b

z-Φd

H

H44H/W/Y-900Lb

2″

50

368

216

165.1

92

38.5

8-Φ26

220



21/2″

65

419

244

190.5

104.7

41.5

8-Φ29

250



3″

80

381

241

190.5

127

38.5

8-Φ26

270



4″

100

457

292

234.9

157

44.5

8-Φ32

330



5″

125

559

349

279.4

185.7

51

8-Φ35

350



6″

150

610

381

317.5

216

56

12-Φ32

420



8″

200

737

470

393.7

270

63.5

12-Φ39

490



10″

250

838

545

469.9

324

70

16-Φ39

550



12″

300

965

610

533.4

381

79.5

20-Φ39

630



14″

350

1029

640

558.8

413

86

20-Φ42

680



16″

400

1130

705

615.9

470

89

20-Φ45

720



18″

450

1219

785

685.8

533.4

102

20-Φ51

750



20″

500

1321

855

749.3

584

108

20-Φ54

800



24″

600

1549

1040

901.7

692

140

20-Φ67

880

H44H/W/Y-1500Lb

2″

50

368

216

165.1

92

38.5

8-Φ26

222



21/2″

65

419

244

190.5

104.7

41.5

8-Φ29

260



3″

80

470

267

203.2

127

48

8-Φ32

270



4″

100

546

311

241.3

157

54

8-Φ35

330



5″

125

673

375

292.1

185.7

73.5

8-Φ42

370



6″

150

705

394

317.5

216

83

12-Φ39

440



8″

200

832

483

393.7

270

92

12-Φ45

510



10″

250

991

584

482.6

324

108

12-Φ51

570
