Product Name: | Wafer Type Check Valve | Type: | Horizontal |
---|---|---|---|
Size: | DN15 ~DN100 | Pressure: | PN16~64 / 150lbs |
Standard: | API 6D/ ANSI 16.5 B/ JIS 20K/JIS 10K | Temperature: | -10~80 C |
Body: | Brass /Bronze | Seat: | Brass /Bronze |
High Light: | non return valve,ductile iron swing check valve |
Horizontal Wafer Type Check Valve , Fool Proof Design Vertical Check Valve
1. Nominal pressure:1.6MPa;
2. Working medium:water;
3 T hread standard: ISO228-1.
Wafer Type Check Valve Advantage:
1. 100% pieces leaking tight test before shipment;
2. Material: Forged brass body & bonnet; Brass flap & nut; Steel pin.
(Brass designation: HPb58-2.5, C37710, CW617N, CW614N, CW602N etc.)
3. Annealing treatment body & bonnet to avoid crack risky, to guarantee the long durable lifetime & safe use;
Wafer Type Check Valve Specifications:
In line with clients' variegated requirements, we bring forth a distinguished collection
of Bronze Swing Check Valve.
It is manufactured in our technically sound manufacturing unit using supreme grade bronze
and cutting edge technology.
The offered valve is used for flow control of liquids and low leakage rate of pipes in different
industries like, food,beverage, gas, water, oil and chemical.
In order to meet the varied needs of clients, it is tested on well defined parameter for ensuring its
perfection. Our clients can avail this Bronze Swing Check Valve within the promised time-frame from
us at affordable prices.
Wafer Type Check Valve Features:
Dimensional accuracy
Corrosion proof
Easy installation
Durability
Wafer Type Check Valve Specification:
BS 5154 PN16
Horizontal Swing pattern
Screwed in Cover
Metal to Metal Seat
ISO228 threaded ends
Suitable for Mounting in horizontal and vertical pipe (with flow upwards).
Valves have fool proof design
Material Specification
Component Material DIN BS
Body : Bronze G-CuSn5ZnPb 1400LG2
Cover : Bronze G-CuSn5ZnPb 1400LG2
Disc : Bronze G-CuSn5ZnPb 1400LG2
Pin : Brass (HT) CuZn39Pb2 2874 - CZ121
Gasket : PTFE PTFE PTFE
Seat : Bronze G-CuSn5ZnPb 1400LG2
DN |
G |
L |
E |
B |
H |
6 |
1/4" |
60 |
10 |
24 |
45 |
10 |
3/8" |
60 |
10 |
24 |
45 |
15 |
1/2" |
65 |
12 |
26 |
48 |
20 |
3/4" |
80 |
17 |
32 |
53 |
25 |
1" |
91 |
20 |
14 |
59 |
32 |
1-1/4" |
104 |
20 |
51 |
70 |
40 |
1-1/2" |
120 |
20 |
58 |
75 |
50 |
2" |
140 |
23 |
69 |
84 |
