Large Image :  DN25 Hose Ball Valve , HIgh Temperature Stainless Steel Ball Valve WRAS / ISO 9001

Product Details:
Place of Origin: Shanghai , China
Brand Name: OEM
Certification: WRAS/ ISO 9001
Model Number: Q41H-16C
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Usually packing by plywood case suit for sea delivery
Delivery Time: 1usually within 35 days after received your payment
Payment Terms: T/T advance or L/C at sight
Supply Ability: 90,000pcs per month
Detailed Product Description
Product Name: Ball Valve Application: Water, Oil, Gas Etc.,
Size: DN15 ~DN250 Pressure: PN16 / 150lbs
Standard: ANS I/ JIS / API / ASME / DIN / BS / Temperature: -20~429 C
Body: Cast Steel/ Ductile Iron/ Stainless Steel Ball: Stainless Steel/ SS304/SS316/SS201
Seat: Stainless Steel
High Light:

flanged ball valves

,

stainless steel ball float valve

DN25,2pc-Flanged /Hose Ball Valve ,Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,High Temperatures







1) Ball Valve (1" ) DN25,2pc-Flanged /Hose Ball Valve ,Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)





2) Ball Valve ( 1 1/4" ) DN25,2pc-Flanged /Hose Ball Valve, Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)





3) Ball Valve (3/4" ) DN25,2pc-Flanged /Hose Ball Valve, Blowout Proof Stem, Anti-Static Design ,PN16,EN1092-1,RF,Working Temperatures (-29C to +427C)



DN25 Hose Ball Valve , HIgh Temperature Stainless Steel Ball Valve WRAS / ISO 9001 0



BALL VALVE:



W.N.R.F. Flanged Ball Valves, Full bore, lever operated, ANSI Class 150/300. Dimensions

API 6D and, tests to API with following parameters:



Body Material               : ASTM A216 WCB

Ball and Trim Material : Stainless Steel

Lever Material              : Forged steel with Zn coated

Seat Material                 : PTFE

Working Temperature   : 05°C to 50°C

Working Pressure          : 150 Psig./350 Psig.

Fluid to be handled        : Natural Gas

(Odorized) containing 0.5% CO2 by volume.



Technical Specification

- Nominal diameter: 1/2”-25”

- Applicable Temperature: -29℃~425℃(steel) -40℃~550℃(stainless steel)

- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs PN16/25/40/64/100/160, JIS 5K /10K/20K

- Applicable Medium: water ,gas,oil,and other causticity medium.



Applications Standard

- Manufacture standard : API 608/ DIN/ BS/JIS

- Face to face dimension: ANSI B 16.10,API 6D/ DIN/ BS/JIS

- Flange dimension: ANSI B 16.5 MSS-SP-44/ DIN/ BS/JIS

- Test: API 598 API 6D/ DIN/ BS/JIS



Description:

The ball valve is designed and manufactured according well to API 608. Floating ball when small caliber,

and fixed ball when large caliber.



It has fire protection structure and antistatic device. Widely used for petroleum, chemistry, water

treatment industries.



Features:



- Anti-blowout Structure of Valve Stem



When medium pass through the valve, the pressure in valve body may possibly push the stem out, or

 when the valve is in repair, if there is pressure in the middle cavity, the stem or medium seems to easily

fly out upon disassembling the valve, which can cause injures to human beings, To prevent the

possibilities, a dummy club is packing and thrust bearing are burnt or packing is damaged due to other

causes, the pressure of medium in valve body will make the dummy club of valve stem in close contact

with the upper seal face of valve body. Thus to prevent medium leaking out from the damage packing

 position.



- Reliable Seal Structure



The seat is made of PTFE. Because the contact area between seat and the ball will becomes more high

 with rising of pressure of the middle cavity, Small Resistance ball valve has the smallest resistance of all

 the valve, in the case of reduced bore, the resistance is little still.



-Prompt switch



The ball valve circumrotates in 90°,It work quickly to open or close.



Test Pressure

Test Item

 Shell Test

 Seal Test

 Back Seal Test

Air Seal Test

 Medium

 Water

 Air

 Unit

MPa

Lbf/in2

MPa

Lbf/in2

MPa

Lbf/in2

MPa

Lbf/in2

 Pressure (Class)

150

3.1

450

2.2

315

2.2

315

0.5-0.7

60-100

300

7.8

1125

5.6

815

5.6

815

400

10.3

1500

7.6

1100

7.6

1100

600

15.3

2225

11.2

1630

11.2

1630

900

23.1

3350

16.8

2440

16.8

2440




 Main Connection Dimensions



DN25 Hose Ball Valve , HIgh Temperature Stainless Steel Ball Valve WRAS / ISO 9001 1

Type

Size(mm)

 Dimension(mm)

inch

DN

L

D

D1

D2

b

Z-Φd

H

W

Q41F/H/Y-150Lb
Q341 F/H/Y-150Lb
Q641 F/H/Y-150Lb

1/2″

15

108

89

60.5

35

12

4-Φ15

68

115

3/4″

20

117

98

70

43

12

4-Φ15

75

130

1″

25

127

108

79.5

51

12

4-Φ15

85

150

11/4″

32

140

117

89

64

13

4-Φ15

96

190

11/2″

40

165

127

98.5

73.2

15

4-Φ15

107

230

2″

50

178

152

120.7

92

16

4-Φ19

118

240

21/2″

65

190

177.8

139.7

104.7

18

4-Φ19

145

280

3″

80

203

190.5

152.4

127

19

4-Φ19

160

310

4″

100

229

229

190.5

157

24

8-Φ19

185

330

5″

125

356

254

216

185.7

26

8-Φ22

230

600

6″

150

394

279

241.3

216

26

8-Φ22

260

800

8″

200

457

343

298.5

270

29

8-Φ22

310

1000

10″

250

533

406

362

324

31

12-Φ25

350

1200





 Type

 Size(mm)

 Dimension(mm)



inch

DN

L

D

D1

D2

b

Z-Φd

H

W

Q41F/H/Y-300Lb
Q341F/H/Y-300Lb
Q641F/H/Y-300LbY

1/2″

15

140

95

66.5

35

15

4-Φ15

72

115



3/4″

20

152

117

82.5

43

16

4-Φ19

75

130



1″

25

165

124

89

51

18

4-Φ19

85

150



11/4″

32

178

133

98.5

64

19.5

4-Φ19

95

180



11/2″

40

190

156

114.3

73.2

21

4-Φ22

110

230



2″

50

216

165

127

92

23

8-Φ19

120

240



21/2″

65

241

190.5

149.4

104.7

26

8-Φ22

150

280



3″

80

283

210

168.5

127

29

8-Φ22

165

310



4″

100

305

254

200.2

157

32

8-Φ22

190

330



5″

125

381

279

235

185.7

35

8-Φ22

240

600



6″

150

403

318

270

216

37

12-Φ22

270

800



8″

200

502

381

330

270

42

12-Φ25

315

1000



10″

250

568

445

387.5

324

48

16-Φ29

380

1200





 Type

 Size(mm)

Dimension(mm)



inch

DN

L

D

D1

D2

b

Z-Φd

H

W

Q41F/H/Y-600Lb
Q341F/H/Y-600Lb
Q641F/H/Y-600Lb

1/2″

15

165

95

66.5

35

15

4-Φ15

88

115



3/4″

20

190

118

82.5

43

16

4-Φ19

98

130



1″

25

216

124

89

51

18

4-Φ19

105

150



11/2″

40

241

156

114.3

73.2

23

4-Φ22

135

180



2″

50

292

165

127

92

26

8-Φ19

155

240



3″

80

356

210

168.2

127

32

8-Φ22

175

280



4″

100

432

273

216

157

38

8-Φ25

210

330



6″

150

559

356

292

216

48

12-Φ29

340

800



8″

200

660

419

349

270

56

12-Φ32

400

1000



10″

250

787

508

432

324

64

16-Φ35

440

1200
