Multi Functional Steam Flanged Check Valve / Reduce Bore Quiet Check Valve

China Multi Functional Steam Flanged Check Valve / Reduce Bore Quiet Check Valve supplier

Large Image :  Multi Functional Steam Flanged Check Valve / Reduce Bore Quiet Check Valve

Product Details:

Place of Origin: Shanghai , China
Brand Name: OEM
Certification: ISO 9001/ API 6D
Model Number: H14 /H64

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Usually packing by plywood case suit for sea delivery
Delivery Time: 1usually within 35 days after received your payment
Payment Terms: T/T advance or L/C at sight
Supply Ability: 90,000pcs per month
Contact Now
Detailed Product Description
Product Name: Steam Flanged Check Valve Name: Multi Functional
Size: 1/4"~ 3" Pressure: 150lbs~2500lbs
Standard: API 6D/ ANSI 16.5 B Temperature: -29~425 C
Body: A105 Trim: 13CR

Multi Functional Steam Flanged Check Valve / Reduce Bore Quiet Check Valve



Steam Flanged Check Valve SPECIFICATIONS



1. Design & Manufacture Conform to:
• API 602, BS5352, ASME B16.34/B16.11/B1.20.1/B16.25
2. Valve Size: 1/2"~2"
3. Applicable Rating: Class 150LB~1500LB
4. Temperature Rating: Up to 500 ℃
5. Structure Features:
• End Connection: Threaded, Socket-Welded or Butt-Welded
• Bolted Cover
• Reduce Bore/ Full Bore







ppicable Rating Valve Size Dimension (mm)
 Reduce Port
    L d D L1 FNPT H
800LB 1/2" 79 Φ13.0 Φ21.8 10.0  1/2" 58
3/4" 92 Φ13.0 Φ27.2 13.0  3/4" 58
1" 111 Φ18.0 Φ33.9 13.0  1" 75
11/4" 120 Φ24.0 Φ42.7 13.0  11/4" 83
11/2" 120 Φ29.0 Φ48.8 13.0  11/2" 94
2" 140 Φ36.5 Φ61.2 16.5  2" 107
1500LB 1/2" 111 Φ13.0 Φ21.8 10.0  1/2" 75
3/4" 111 Φ13.0 Φ27.2 13.0  3/4" 75
1" 120 Φ18.0 Φ33.9 13.0  1" 83
11/4" 120 Φ24.0 Φ42.7 13.0  11/4" 94
11/2" 140 Φ29.0 Φ48.8 13.0  11/2" 107
2" 160 Φ36.5 Φ61.2 16.5  2" 130



Appicable Rating Valve Size Dimension (mm)
 Full Port
    L d D L1 FNPT H
800LB 1/2" 79 Φ13.0 Φ21.8 10.0  1/2" 58
3/4" 111 Φ13.0 Φ27.2 13.0  3/4" 75
1" 120 Φ18.0 Φ33.9 13.0  1" 83
11/4" 120 Φ24.0 Φ42.7 13.0  11/4" 94
11/2" 140 Φ29.0 Φ48.8 13.0  11/2" 107
2" 178 Φ36.5 Φ61.2 16.5  2" 141
1500LB 1/2" 111 Φ13.0 Φ21.8 10.0  1/2" 75
3/4" 120 Φ13.0 Φ27.2 13.0  3/4" 83
1" 120 Φ18.0 Φ33.9 13.0  1" 94
11/4" 140 Φ24.0 Φ42.7 13.0  11/4" 107
11/2" 160 Φ29.0 Φ48.8 13.0  11/2" 130
2" 178 Φ36.5 Φ61.2 16.5  2" 141





STANDARD MATERIALS



PART NAMES MATERIALS-SWING CHECK VALVE
BODY

A105; LF2; F5; F11; F22; F304(L); F316(L); F347; F321; F51;

                 F55; Inconel; Monel; Hastelloy C; etc.

BONNET

A105; LF2; F5; F11; F22; F304(L); F316(L); F347; F321; F51;

                 F55; Inconel; Monel; Hastelloy C; etc.

SEAT ASTM A276 410+HF
DISC ASTM A276 420
GASKET 304+ GRAPHITE
COVER BOLT ASTM A193 B7
ROCKER ASTM A351 CF8





SPECIFICATIONS

1. Design & Manufacture Conform to:
  • API 602, BS5352, ASME B16.34/B16.11/B1.20.1/B16.25
2. Valve Size: 1/2"~2"
3.  Applicable Rating: Class 150LB~1500LB
4. Temperature Rating: Up to 500  ℃
5. Structure Features:
  • End Connection: Threaded, Socket-Welded or  Butt-Welded
  • Bolted Cover
  • Reduce Bore/  Full Bore
