SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM

SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM
SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM

Large Image :  SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM

Product Details:
Place of Origin: Shanghai , China
Brand Name: OEM
Certification: ISO 9001
Model Number: Q11F / Q11
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiation
Packaging Details: Usually packing by plywood case suit for sea delivery
Delivery Time: usually within 35 days after received your payment
Payment Terms: T/T advance or L/C at sight
Supply Ability: 90,000pcs per month
Detailed Product Description
Product Name: Ball Valve Application: Air , Water, Oil, Gas Etc.,
Size: 1/4" ~ 4" Pressure: 150lbs~2500lbs/JIS 10K~20K /PN16~PN160
Standard: DIN / BS / ANS I/ JIS / API / ASME Temperature: -10~120 Cenius
Body: Stainless Steel / SUS304 / SUS316 Ball: Stainless Steel/ SS304/SS316/SS201
High Light:

stainless steel ball float valve

,

trunnion mounted ball valve

OEM Brand Ball Valve, Full Bore, Body / Ball: Stainless Steel CF8M (SS316), Threaded End To BS 21



OEM brand  ball valve, full bore
body  : Stainless steel CF8M ( SS 316)
ball  : Stainless steel CF8M ( SS 316)
shaft: Stainless steel 316
seats: PTFE
operation:  with Stainless steel  lever
internal fastenings:  Stainless steel 316 (A4)
working  pressure    : 16 bar at max. 40 deg. C
seat leakage: no visible leakage as specified in EN 12266-1
application :  lime solution or alum solution
Threaded endsd to BS 21



Brief introduction:

The ball valve is designed and manufactured according well to API 6D.  Floating ball when small

caliber, and fixed ball when large caliber. It has fire protection structure and antistatic device.

Widely used for petroleum,chemistry,water treatment industries.



Main part & material

Part name

Material

body

WCB,ZG1Cr18Ni9Ti,CF8

ball

1Cr18Ni9Ti 304,316

stem

1Cr18Ni9Ti 304,316

seal ring

Polytetrafluoroethlene(PTFE)

packing

Polytetrafluoroethlene(PTFE)



SUS304 3 Way Ball Valve Threaded End To BS 21 PTFE Seats OEM 0















DN

G

B

L

H

A

6

1/4"

8

65

57

98

10

3/8"

10

65

57

98

15

1/2"

15

75

68

125

20

3/4"

20

85

70

125

25

1"

25

95

80

145

32

1-1/4"

32

110

84

145

40

1-1/2"

38

125

93

205

50

2"

50

150

100

205

65

2-1/2"

64

175

142

250

80

3"

76

216

155

265

100

4”

100

260

172

300



Technical Specification

Nominal pressure(Mpa)

PN

2.5,4.0,6.4

Strength testing pressure(Mpa)

PT

3.8,6.0,9.6

Low pressure seal test(Mpa)



0.6

High pressure seal test(Mpa)



3.0,4.8,7.6

Applicable medium

water, oil, gas, nitric acid, acetic acid

Applicable temperature

-40~180℃



Feature:

-  Anti-blowout Structure of Valve Stem

When medium pass through the valve, the pressure in valve body may possibly

push the stem out, or when the valve is in repair, if there is pressure in the middle

cavity, the stem or medium seems to easily fly out upon disassembling the valve,

which can cause injures to human beings,



To prevent the possibilities, a dummy club is packing and thrust bearing are burnt

or packing is damaged due to other causes, the pressure of medium in valve body

will make the dummy club of valve stem in close contact with the upper seal face of

valve body.



Thus to prevent medium leaking out from the damage packing position.



-  Reliable Seal Structure

The seat is made of PTFE. Because the contact area between seat and the ball will

becomes more high with rising of pressure of the middle cavity,



Small Resistance ball valve has the smallest resistance of all the valve, in the case

of reduced bore, the resistance is little still.



-  Prompt switch

The ball valve circumrotates in 90°,It work quickly to open or close.





Specifications:

Technical Specification

- Nominal diameter: 1/2”-25”

- Applicable Temperature: -29℃~425℃(steel) -40℃~550℃(stainless steel)

- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs PN16/25/40/64/100/160, JIS 5K /10K/20K

- Applicable Medium: water ,gas,oil,and other causticity medium.



Applications Standard

- Manufacture standard : API 608/ DIN/ BS/JIS

- Face to face dimension: ANSI B 16.10,API 6D/ DIN/ BS/JIS

- Flange dimension: ANSI B 16.5 MSS-SP-44/ DIN/ BS/JIS

- Test: API 598 API 6D/ DIN/ BS/JIS



Description:

Brief introduction:

The ball valve is designed and manufactured according well to API 608. Floating ball when small caliber,

and fixed ball when large caliber.



It has fire protection structure and antistatic device. Widely used for petroleum, chemistry, water

treatment industries.



Features:



- Anti-blowout Structure of Valve Stem



When medium pass through the valve, the pressure in valve body may possibly push the stem out, or

 when the valve is in repair, if there is pressure in the middle cavity, the stem or medium seems to easily

fly out upon disassembling the valve, which can cause injures to human beings, To prevent the

possibilities, a dummy club is packing and thrust bearing are burnt or packing is damaged due to other

causes, the pressure of medium in valve body will make the dummy club of valve stem in close contact

with the upper seal face of valve body. Thus to prevent medium leaking out from the damage packing

 position.



- Reliable Seal Structure



The seat is made of PTFE. Because the contact area between seat and the ball will becomes more high

 with rising of pressure of the middle cavity, Small Resistance ball valve has the smallest resistance of all

 the valve, in the case of reduced bore, the resistance is little still.



-Prompt switch



The ball valve circumrotates in 90°,It work quickly to open or close.
